CPFC series box type flat film module

Kanpur flat membrane components are made of PTFE membrane material, which has strong anti pollution ability, low filtration resistance, and can achieve gravity filtration. The Kanpur CPFC series box type flat membrane module adopts a unique box combination method, with high filling density and large filtration area. Membrane components can be stacked and arranged, with a small footprint, simple system integration, and low operating costs.

Product Features

Polytetrafluoroethylene (PTFE) membrane material

Polytetrafluoroethylene (PTFE) has extremely strong chemical stability and surface properties that do not adhere to any substances. Kamper PTFE flat film can withstand strong acids, alkalis, and oxidants for better cleaning effect and stronger anti pollution ability.

Permanent hydrophilicity

Kanpur flat membrane components use proprietary technology to achieve permanent hydrophilicity of PTFE membranes. Pure water flux greater than 1000L/m ² · hr, at 1 mH2O.

Gravity filtration membrane

Kanpur PTFE membrane is manufactured using biaxial stretching process, with a porosity of over 80% and extremely low filtration resistance. The transmembrane pressure difference under general flux is less than 0.5mH2O, which makes gravity filtration (pumpless filtration) possible.

Open box structure

The Kanpur box type flat membrane module adopts a structure with open upper and lower ends, which can effectively avoid entanglement and blockage of hair and paper scraps in sewage, as well as sludge deposition.

High filling density

The Kanpur box type flat membrane module adopts a unique multi-layer combination of the box body, which significantly improves the filling density of the membrane module.

Stacked arrangement is energy-saving and efficient

The Kampel box type flat membrane module is placed in multiple layers, greatly reducing the projection area of the MBR membrane system, thus greatly reducing the amount of aeration during operation and making the membrane system operating at a lower cost.

Application fields of MBR box type flat film

Urban sewage treatment

Residential area sewage treatment Industrial sewage treatment

Advanced sewage treatment and recycled water treatment

Membrane enhanced bioreactor (MEBR)
