CPO series external pressure ultrafiltration membrane components

The Kamper external pressure membrane module has the characteristics of sufficient aeration, strong pollution resistance, strong chemical resistance, and low pressure and high flux. Kamper external pressure ultrafiltration membrane can effectively reduce the turbidity of raw water, remove suspended solids, colloids, microorganisms and other substances in water, and has strong adaptability to changes in raw water quality. It is easy to operate and maintain, and the quality of produced water is stable and reliable.

Product Features

Composite thermally induced phase separation PVDF ultrafiltration membrane

Kamper PVDF external pressure ultrafiltration membrane is manufactured using a unique composite thermally induced phase separation (c-TIPS) technology. Its membrane filament strength is greater than that of PVDF membrane prepared by traditional immersion precipitation method (NIPS), and its filtration accuracy is higher than that of PVDF membrane prepared by ordinary thermally induced phase separation method (TIPS).

Permanent hydrophilicity

By adding hydrophilic substances and special cross-linking techniques during the preparation process, Kamper external pressure ultrafiltration membranes can permanently retain their hydrophilicity, stabilize water production flux, and significantly improve their pollution resistance and cleaning recovery.

High antioxidant activity

Kamper PVDF external pressure ultrafiltration membrane has high crystallinity and can tolerate higher concentrations of oxidants, thus achieving more thorough cleaning effect and longer lifespan.

High intensity and high flux

The average breaking tensile strength of Kamper external pressure ultrafiltration membrane fibers is 8N, with a standard water production flux of 400L/m ² • h • bar at 25 ℃.

Unique aeration structure

The Kamper external pressure ultrafiltration membrane module adopts a unique internal aeration device to ensure more uniform aeration and better air scrubbing effect.

Bundle integrated distribution

Kamper external pressure ultrafiltration membrane components have more beam splitting compared to similar products, effectively ensuring a more uniform distribution of water flow inside the components.

Soft rubber root protection

Kamper's pioneering soft rubber pouring technology has achieved flexible connection between the root of the membrane wire and the pouring layer, eliminating the hidden danger of membrane wire root fracture.

Application Fields of Ultrafiltration Membrane

Tap water and drinking water treatment

Pre treatment of reverse osmosis and nanofiltration devices

Deep treatment and reuse of sewage

Filtration and purification treatment of cooling water and condensate water
